如下為我司愛澤工業IZE_Industries本月到貨HUBBELL相關產品，歡迎致電索取樣本資料和產品信息。

HUBBELL隔離開關HBLDS3

HUBBELL插頭HBL2721

HUBBELL插座HBL2720

HUBBELL插頭CS8365

HUBBELL插座HBL2720SW

HUBBELL隔離開關HBLDS3產品介紹

開關和照明控制器，工業級，無熔斷器隔離開關，三極，30A 600V 交流電，螺釘端子，灰色，NEMA4X 外殼。

體驗工業級無熔斷器隔離開關的可靠和強勁性能。這款三極、30A、600V 交流電開關采用耐用的螺釘端子，并封裝在 NEMA 4X 外殼中，可有效防塵、防水和防腐蝕。這款無熔斷器隔離開關非常適合各種工業應用，旨在提供安全高效的電源控制方式。其堅固的結構和符合安全標準的要求，使其成為需要高防護等級和可靠性的環境的理想選擇。

Switches and Lighting Controls, Industrial Grade, Non-fused Disconnect Switch, Three Pole, 30A 600V AC, Screw Terminals, Gray, NEMA4XEnclosure.

Experience reliable and robust performance with our Industrial Grade Non-Fused Disconnect Switch. This three-pole, 30A, 600V AC switch features durable screw terminals and is housed in a NEMA 4X enclosure, ensuring protection against dust, water, and corrosion. Perfect for a variety of industrial applications, this non-fused disconnect switch is designed to provide a safe and efficient means of controlling power. Its rugged construction and compliance with safety standards make it an ideal choice for environments requiring a high degree of protection and reliability.

HUBBELL插頭HBL2721產品介紹

鎖定裝置，Twist-Lock®，工業級，公插頭，30A 三相 250V 交流電，三極四線接地，L15-30P，螺絲端子，黑白配色。

• 線夾設計，防止端接過度拉力。

• 清晰的漏斗形電線入口，方便端接。

• 一體式防塵罩，防止接線腔受灰塵或污染物影響。

Locking Devices, Twist-Lock®, Industrial, Male Plug, 30A 3-Phase 250V AC, 3-Pole 4-Wire Grounding, L15-30P, Screw Terminal, Black and White.

• Superior cord grip design protects terminations from excess strain.

• Clear, funnel shaped wire entry for ease of termination.

• Integral dust shield protects wiring chamber from dust or contaminants.

HUBBELL插座HBL2720產品介紹

鎖定裝置，Twist-Lock®，工業級，嵌入式插座，30A 三相 Delta 250V 交流電，三極四線接地，L15-30R，螺絲端子，黑色。

• 背面和側面均設有導線限制凹槽，大大降低了端子連接松動的可能性。

• 表面按電壓顏色編碼，方便定位和連接合適的設備。

• 全黃銅安裝和接地系統，比鋼制安裝系統提供更低的接地電阻和更強的耐腐蝕性。

Locking Devices, Twist-Lock®, Industrial, Flush Receptacle, 30A 3-Phase Delta 250V AC, 3-Pole 4-Wire Grounding, L15-30R, Screw Terminal, Black.

• Wire restraint recess for both back and side wiring, greatly reduces the possibility of loosening the terminal connection

• Face color coding by voltage facilitates locating and mating of proper devices

• All-brass mounting and grounding system provides a lower resistance ground path and greater resistance to corrosion than steel mounting systems

HUBBELL插頭CS8365產品介紹

工業級鎖定裝置，公插頭，50A 三相 Delta 250V 交流電，三極四線接地，非 NEMA 標準，螺絲端子，重型黑色

• 高強度尼龍外殼，抗沖擊性能更佳

• 不銹鋼護罩保護觸點，防止誤配

• 盒式端子帶內六角螺紋插頭，可在導線上施加高夾緊力，且不會損壞線芯

• 熱塑性聚酯內襯，耐熱且抗沖擊

Locking Devices, Industrial, Male Plug, 50A 3-Phase Delta 250V AC, 3-Pole 4-Wire Grounding, Non-NEMA, Screw Terminal, Heavy Duty Black

• Super tough nylon housing offers better impact qualities

• Stainless steel shroud protects contacts and prevents mismating

• Box terminal with hex socket threaded slug, permits high clamping pressure on conductors without damaging strands

• Thermoplastic polyester interior provides heat resistance and impact strength

HUBBELL插座HBL2720SW產品介紹

鎖定裝置，Twist-Lock®，防水安全罩®，插座，30A 三相 Delta 250V 交流電，三極四線接地，NEMA L15-30R，螺絲端子，PBT 外殼和法蘭，灰色。

• 耐沖擊熱塑性外殼，適用于重載工業環境

• 帶有鎖定和解鎖符號的對準箭頭，可直觀指示設備是否已正確連接

• 即使在使用過程中，產品目錄號和顏色編碼的額定電壓也清晰可見

Locking Devices, Twist-Lock®, Watertight Safety-Shroud®, Receptacle, 30A 3-Phase Delta 250V AC, 3-Pole 4-Wire Grounding, NEMA L15-30R, Screw Terminal, PBT housing and flange, Gray.

• High impact, thermoplastic housing for heavy-duty industrial environments

• Alignment arrows with lock and unlock symbols provide a visual indication that devices are properly connected

• Catalog number and color coded voltage rating are visible even when in use

HUBBELL工業連接和控制產品常用型號：

HUBBELL HBL2735ST

HUBBELL HBL2825ST

HUBBELL HBL2815ST

HUBBELL HBL2721ST

HUBBELL HBL2731ST

HUBBELL HBL2715ST

HUBBELL HBL2821ST

HUBBELL HBL2811ST

HUBBELL HBL2725ST

HUBBELL HBL2425ST

HUBBELL HBL2411ST

HUBBELL HBL2711ST

HUBBELL HBL2421ST

HUBBELL CS6375

HUBBELL CS6369

HUBBELL CS8375LC

HUBBELL CS8375L

HUBBELL CS8369L

HUBBELL CS8365L

HUBBELL CS8364L

HUBBELL CS6375LC

HUBBELL CS6375L

HUBBELL CS6369L

HUBBELL CS6365L

HUBBELL CS6364L

HUBBELL CS8375MBWP

HUBBELL CS8475A

HUBBELL CS8469A

HUBBELL CS8465

HUBBELL HBL2720SW

HUBBELL HBL2720AR

HUBBELL HBL2720SR

HUBBELL HBL2720SR2

HUBBELL HBL2720

HUBBELL HBL2720ST

HUBBELL HBL2720RT

HUBBELL HBL2726

HUBBELL HBL2726ST

HUBBELL HBL2710

HUBBELL HBL2730

HUBBELL HBL2740

HUBBELL HBL2750

HUBBELL HBL2760

HUBBELL HBL2770

HUBBELL HBLDS10RCJ

HUBBELL HBLDS6RCJ

HUBBELL HBLDS6PJ

HUBBELL HBLDS6SSPAC

HUBBELL HBLDS6PAC

HUBBELL HBLDS10RCPJ

HUBBELL HBLDS6RCPJ

HUBBELL HBLDS10PAC

HUBBELL HBLDS6RCP

HUBBELL HBLDS10RCP

HUBBELL HBLDS20

HUBBELL HBLDS20SS

HUBBELL HBLDS3PJ

HUBBELL HBLDS3P

HUBBELL HBLDS3VFDJ

HUBBELL HBLDS3

如果您需要完整的HUBBELL的相關技術咨詢，請隨時致電愛澤工業或者訪問網站,我們將盡全力解決您的問題。

If you have any question for HUBBELL，Please feel free to communicate with us and we will do our best to solve your problem.
